Cyber Power CPS5000ECH48 - PV Mode Electrical Specifications; PV Mode Performance Parameters; General Unit Specifications; Safety, Environment, and Dimensions

26
PV Mode Specifications:
Table7-3
INVERTER MODEL
CPS3000ECH48
CPS5000ECH48
PVA MAX Power
1750W
PVB MAX Power
1750W
PVA MAX input current
30A
PVB MAX input current
30A
Total PV MAX charge current
70A
Efficiency
98.0% MAX
Max. PV Array Open Circuit
Voltage
145VDC
PV Array MPPT Voltage Range
60-115VDC
General Specifications:
Table7-4
INVERTER MODEL
CPS3000ECH48
CPS5000ECH48
Safety Certification
CE
Operating Temperature Range
0
℃
-55
℃
Storage Temperature
-15
℃
-60
℃
Protection
Over Temperature
Over Voltage
Output Short
Over Load
Noise
<48dB
Dimension (D*W*H, mm)
470x440x120
Net Weight (kg)
12.5
