9. In order to ensure machine can run normally and easy to operate, please pay attention to provide
adequate space for the inverter. Please refer to below:
Figure 3-2
10. Do not install the machine near television antenna or any other antennas and antenna cables.
11. Do not install the machine in the living area.
12. Be sure that the machine is out of the children’s reach.
13. Install the unit by screwing three crews as below. It’s recommended to use M6 screws.
248mm(9.76")
380mm(14.96")
69mm(2.71")
Figure 3-3
