DOC ID: 16001100

Page | 13

SIM Card Slots

MiniPCIe Slot/SIM Slot/WLAN LED Mapping Table:

Mini PCIe

SIM

LED

Mini PCIe 1

SIM 1 (CN9)

1

Mini PCIe 2

SIM 2 (CN10)

2

Mini PCIe 3

SIM 3 (CN11)

3

Note: The SIM card slots do not support hot-plug functionality. Please make sure to

unplug system power before inserting the SIM card(s).
