PRODUCT OVERVIEW - BASIC CONFIGURATION
Front Panel
Rear Panel
BM Port
Connection port for built-in battery management module on UPS and Extended Battery Module.
Refer to Basic Operation section in Product Overview.
Battery Cover
Front Panel Access Tabs
Faceplate
AC Inlet
Input Circuit Breaker
AC Outlet
Extended Battery Module Connector Plug
Extended Battery Module Connector Socket
Fuse Cover
BM Port
1
1
4
2
2
5
3
3
6
7
