SMART APP SERIES
OL6000RT3UTF SPECIFICATIONS
GENERAL
UPS Topology Double-Conversion Online
Energy Saving ECO Mode Efficiency >95%
INPUT
Voltage 200 – 240Vac
Input Frequency Range 40Hz – 70Hz (auto-sensing)
Input Power Factor 0.99
Cold Start Yes
Backfeed Protection Yes
Plug Style NEMA L6-30P
Cord Length (FT) 6
OUTPUT
VA 6,000 (6 kVA)
Watts 5,400 (5.4 kW)
On Battery Waveform Sine Wave
On Battery Voltage
120Vac; 200, 208, 220, 230,
240Vac (Configurable) ±2%
On Battery Frequency
50/60Hz (Auto-Sensing or
Configurable) ±0.25Hz
Rated Power Factor 0.9
Harmonic Distortion
THD < 3% at Linear Load,
< 5% at Non-linear Load
Crest Factor 3:1
ECO Mode Voltage Regulation ±10%, ±15% (Configurable)
Outlets - Total 15
Outlet Type
NEMA L6-20R (2)
NEMA L6-30R (1)
NEMA 5-20R (12)
Bypass
Internal Bypass
(Automatic and Manual)
Transfer Time 0 ms
SURGE PROTECTION & FILTERING
Surge Suppression
Network Grade
Surge Protection
Phone / Network Protection
RJ11/RJ45
1-In / 1-Out
EMI/RFI Filtration Yes
BATTERY
Runtime at Half Load (min.) 15.8
Runtime at Full Load (min.) 5.3
Battery Type Sealed lead acid
Battery Size 12V/7.2AH
Battery Quantity 20
User Replaceable Yes
Hot Swappable Yes
Typical Recharge Time
4 Hours (*2.5 w/Fast Charge
Technology)
Smart Battery Management
(SBM) Mode
Yes
Expandable Battery
Module Option
BP240V30ART3U
MANAGEMENT & COMMUNICATIONS
LCD Control Panel
The LCD control panel
enables users to check 38
different settings or status
options via the UPS Status
menu, UPS Setup menu and
run Testing menus. Refer to
the "Function Setup Guide"
on the "Resources" tab for
complete options.
Removable LCD Control Panel
Yes - Requires a separate
DB26 Cable
(Two Ports - Front/Back)
HID Compliant USB Port Yes
Serial Port Yes
EPO Port Yes
Dry Contacts Yes
Management Cable USB Cable, Serial Cable
LED Indicators
Power On (White),
Line Mode (Green), Battery
Mode (Yellow), Bypass Mode
(Yellow), Fault (Red), Replace
Battery (Red)
Audible Alarms
Battery Mode, Battery Low,
Overload, UPS Fault,
Replace Battery
MANAGEMENT & COMMUNICATIONS (CONT.)
Software PowerPanel
®
Business Edition
SNMP / HTTP Remote
Monitoring
Yes - Optional RMCARD302
or RMCARD303
PHYSICAL
Form Factor Rack / Tower Convertible
Power Module, Battery Module and Step-down Tranformer
Dimensions (WxHxD) (in.) 17 x 14 x 26
Dimensions (WxHxD) (mm.) 433 x 355.6 x 660
Weight (lbs.) 348.3
Weight (Kg.) 158.3
Installed Rack Height 8U
Enclosure ConStruction Steel
Mounting Hardware Included: Yes
ENVIRONMENTAL
Operating Temperature
32 °F to 104°F
0°C to 40 °C
Operating Humidity 0% – 90% non condensing
Operating Elevation
0 – 10000 feet
0 – 3000 meters
Storage Temperature 5 – 113 °F (-15 – 45 °C)
Storage Relative Humidity 0% – 95% non condensing
Storage Elevation
0 – 50000 feet
0 – 15000 meters
Audible noise at 1.5M from
surface of unit
55 dBA
Online Thermal Dissipation 2048 BTU/hr
CERTIFICATIONS
Certifications
UL1778,
CSA C22.2 NO.107.3-05,
FCC DOC Class A
ROHS ROHS Compliant
WARRANTY
Product Warranty 3 Years Limited
Connected Equipment
Guarantee
Lifetime
CEG Amount $300,000
© 2013 CyberPower Systems (USA), Inc. All rights reserved. All other trademarks are the property of their respective owners. CyberPower reserves the right to modify product information or specifications without previous notice. The information presented is accurate at the time of publication. 10-2013
CyberPower Systems, Inc. designs and manufactures state-of-the-art power protection and distribution equipment for corporate, business, home, government and educational markets. CyberPower leads the industry by surpassing customer expectations in the
development, design, construction, durability and functionality of uninterruptible power supply (UPS) products for computers, peripherals and connected devices. CyberPower Systems operates in the Asian Pacific, North American and European markets.
For additional information, including sales office locations and authorized reseller partners, visit CPSww.com.
*Fast Charge Technology requires the External Battery Module (EBM) to be connected to a 208Vac utility power source.
