CyberPower RMCARD205 User Manual

CyberPower Remote Management System
6
Installation Guide
Step 1. Hardware Installation
Note: The CyberPower Remote Management Card is hot-swappable, so you do not need
to turn off the UPS to install it.
1. Remove the two retaining screws from the expansion slot and remove the cover.
2. Install the CyberPower Remote Management Card into the expansion slot.
3. Insert and tighten the retaining screws.
4. Connect an Ethernet cable to the Ethernet port of the CyberPower Remote
Management Card.
5. (Optional) To connect an environmental sensor, use a RJ45 Ethernet cable. Connect
one end to the Universal port on the RMCARD and the other end into the sensor. For
more information, please see the ENVIROSENOR user’s manual.
RMCARD205

CyberPower RMCARD205 Specifications

General

AC outlets quantity	- AC outlet(s)
Ethernet LAN (RJ-45) ports	2
Sustainability compliance	Yes
Sustainability certificates	CE, Federal Communications Commission (FCC), RoHS
Country of origin	China
Quantity	1
Product type	Network management card
Product color	Black, Blue
Cabling technology	10/100
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 15000 m
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Supported network protocols	IPv4/v6, SNMPv1/v3, HTTP/HTTPs, TCP/IP, UDP, DHCP, NTP, DNS, SMTP, SSH, SSL, TLS, Telnet, FTP, and Syslog
Cables included	Serial

Weight and Dimensions

Depth	76.5 mm
Width	54 mm
Height	36.1 mm
Weight	160 g
Package depth	60 mm
Package width	170 mm
Package height	165 mm
Package weight	300 g
Dimensions (WxDxH)	172 x 60 x 165 mm
