SECURING THE CHILD SEAT USING THE LATCH-
CONNECT SYSTEM
NOTE! The ISOFIX xture points (6) are two metallic clips for
each seat and are positioned between the backrest and the
seating surface of the vehicle seat. In case of doubt, please refer
to the driver’s manual of your vehicle.
HINWEIS! Note the information in the section “PLACING THE
SEAT IN THE VEHICLE”.
• Elongate the straps of the Latch-Connect System by using the
adjuster (5).
• Attach the Latch-Connect hooks (7) to the ISOFIX attachment
points (6).
• Tighten the Latch-Connect System by pulling the strap on the
adjuster until the position of the child seat is adjusted correctly.
• Ensure that the seat is secure by trying to pull it out of the
ISOFIX xture points (6).
Using the Latch-Connect System system, you can x the
Solution B-x to the vehicle, thereby increasing your child’s
safety. The child still needs to be secured with the three-point
belt of your vehicle.
