CYBEX 625T Installation Instructions

Page 4 of 7
www.cybexintl.com
3. Lift the handset assembly carefully and unplug the following cables: contact heart rate grips
(J7), and handset membrane (J9).
1
2
Description Qty
1 Handset Membrane (J9) 1
2 Contact Heart Rate Grips (J7) 1
Install access cover
1. Remove the two screws securing the access cover to the handset using a Phillips screwdriver.
2
1
3
Description Qty
1 Handset 1
2 Screw 2
3 Access Cover 1
2. Install the two screws securing the new access cover to the handset using a Phillips
screwdriver.
Install iPod board
1. Install the iPod board, four screws, and ground wire as shown using a Phillips screwdriver.
1
2
3
4
Description Qty
1 Handset 1
2 Screws 2
3 Access Cover 1

CYBEX 625T Specifications

General

User Weight Capacity	400 lbs
Speed Range	0.5 - 12.4 mph
Incline Range	0% to 15%
Display	LED
Heart Rate Monitoring	Contact and wireless
Running Area	60" x 20" (152 x 51 cm)
