Cybex 700C Cycle and 700R Recumbent Owner’s Manual
Page 2-2
Figure 1
Please refer to Figure 1 (shown below) for “Attach Seat Back Assembly” and “Attach the
Display Upright” sections listed on the next page.
Assembling the 700R Recumbent Cycle
Parts List for the 700R Recumbent Cycle
The following parts are included with 700R Recumbent Cycle:
Part# Qty Description
LT-03151 1 Owner’s Manual
HX-00438 1 Wrench, 3/16 Hex Key
HS-13948 3 5/16-18 x 3/8" Cap Screw
HS-41107 4 5/16-18 x 1-1/2" Cap Screw
HS-41109 7 #10-24 x 3/4" Screw
PL-51670 1 Water Bottle Holder
HW-53018 7 Lock Washer
AX-61026 1 Termination Plug
AW-61033 1 Communications Cable
AX-61309 1 Seat Back Assembly
AX-62014 1 Display Upright
Varies 1 Configuration Kit
Varies 1 Display Console
Varies 1 Main Chassis Base
