Assembly and Setup
Page 2–7
Cybex 750C/750R Owner’s Manual
6. Install the back cap.
A. Locate and place the back cap (#3) into the top
cap as shown in Figure 7. NOTE: Ensure the
back cap is fully inserted into the top cap.
B. Using a Phillips screwdriver, secure with two
screws 8-16 x .50 (#12). See Figure 7.
7. Level the unit.
A. Confirm that the unit is on a level surface. If not,
use a 9/16” open-end wrench to adjust the leveling
feet up or down. See Figure 8.
8. Visually inspect the unit.
A. Carefully examine the unit to ensure that the
assembly is correct and complete.
B. Proceed to Testing the Operation section.
Figure 8
Leveling Feet
Figure 7
#12
#3
