CYBEX Arc Trainer 610A Service Manual

Service
Page 4-30
Pedal Arm and Foot Plates
NOTE: The pedal arms and foot plates are removed in the same way. This procedure can be used for
both.
Tools Required
• Phillips head screwdriver
• 3/16” Allen wrench
• Threadlocker
1. Disconnect the external power source.
A. Turn the main power switch above the power inlet to the off (O) position.
B. Unplug the power cord from the power outlet.
2. Remove the foot plate and pedal arm.
A. Using a Phillips head screwdriver or 3/16” Allen wrench, remove each SHCS securing the
(appropriate) cap. See Figure 25.
B. Remove the cap.
C. Slide the foot plate off the foot plate shafts (if applicable).
D. Slide the (appropriate) arm off the shaft (or shafts).
3. Attach the new foot plate and pedal arm.
A. Slide the (appropriate) arm on the shaft (or shafts).
B. Slide the foot plate on the foot plate shafts (if applicable).
C. Place a drop of threadlocker on one of the SHCS. Place another drop of threadlocker in the
shaft (where the SHCS will be tightened into).
D. Using a Phillips head screwdriver or 3/16” Allen wrench, attach cap with the (appropriate)
SHCS securing the cap. See Figure 25. NOTE: SHCS must be tightened to a minimum of
100 inch-pounds.
Cybex Arc Trainer 610A Service Manual
6. Attach the new handle link.
A. Slide the handle link onto the arm shaft and foot plate arm shaft.
B. Using a Phillips head screwdriver or 3/16” Allen wrench, secure handle link with the screws and
(appropriate) cap removed in step 3A.
7. Connect the contact heart rate cable.
A. Plug the contact heart rate cable into the plug in the main frame. See Figure 23.
