Cybex Arc Trainer 620A/629A Owner’s Manual
Main Assembly
A1 2 11090-404 DECAL, CYBEX
A2 2 11090-405 FOOT PAD
A3 1 600A-200 WELDMENT, LINKAGE ROD RIGHT
A4 1 600A-201 WELDMENT, LINKAGE ROD LEFT
A5 1 600A-301 WARRANTY SHEET ARC
A6 4 600A-311 SPACER, FLANGE
A7 2 600A-331 COVER, CRANK
A8 1 600A-332 COVER, ELEVATION MOTOR
A9 1 600A-333 COVER, RIGHT
A10 1 600A-334 COVER, LEFT
A11 1 600A-335 COVER, FRONT ACCESS
A12 5 600A-336 INSERT, COVER
A13 1 600A-362 LABEL, BIOSIG PATENT
A14 1 610A-201 FOOT PLATE ARM, LR
A15 1 610A-202 FOOT PLATE ARM, RR
A16 1 610A-303 COVER, PIVOT RH
A17 1 610A-304 COVER, PIVOT LH
A18 6 610A-311 RETAINER, PIVOT SHAFT
A19 4 610A-342 PIVOT PIN
A20 4 610A-357 TUBE, SPACER
A21 2 610A-377 RETAINER, PIVOT SHAFT
A22 2 610A-395 ASSY, ARM CRANK
A23 1 620A-200 MAIN FRAME 620A
A23 1 629A-200 MAIN FRAME 629A
A24 1 620A-201 C HANDLE 620A
A25 1 620A-203 FOOT PLATE ARM, LF
A26 1 620A-204 FOOT PLATE ARM, RF
A27 8 620A-328 FOAM, .125 X .125
A28 1 620A-352 POSTER, INSTALLATION
A29 1 630A-101 DRIVE FRAME ASSEMBLY
A30 2 630A-317 FOAM, .25 X .38
A31 2 AF-16694 ASSY, BEARING, 1.00 INCH
PILLOW BLOCK
A32 1 AW-18439 HARNESS, SPA FRAME
A33 2 CM000243 LABEL, BLANK CALIBRATION
A34 2 CW-17231 WHEEL, TENSIONER
A35 1 DE-17317 DECAL, LOGO ARC TRAINER
A36 2 DE-17339 DECAL, CYBEX VORTEX
A37 1 DE-19561 LABEL, ETL MEDICAL
A38 4 FB030244 BEARING, RADIAL BALL .50 ID X
1.688 OD
A39 8 FB030247 BEARING, RADIAL 25MM
EXTENDED RACE
A40 4 FC030004 TOLERANCE RING 42 (1.653) ID
A41 8 FC030007 TOLERANCE RING 2.047 ID
A42 1 FT-17242 SLEEVE, ELEVATION MOUNTING,
TOP
A43 1 FT-17243 SLEEVE, ELEVATION MOUNTING,
BOTTOM
A44 8 HB-17036 BEARING, BALL, .750 DIAMETER
A45 3 HC701226 BOLT, HHCS .375-16 x 2.0
A46 1 HC701230 SCREW, HHCS .375-16 x 2.50
A47 4 HC701232 SCREW, HHCS .375-16 x 2.75
A48 4 HF540200 GROMMET, NYLON
A49 2 HG700022 LEVELING GLIDE, .375-16
A50 8 HM582514 SCREW, PAN HEAD PHILPIPS
10-32 x .62 BLK
A51 2 HN624901 LOCKNUT, .250-20 NYLON BLK ZN
A52 2 HN704000 HEX NUT .375-16
A53 4 HN704901 LOCKNUT, .375-16 NYLON
A54 2 HN704902 LOCKNUT, .375-16 NYLON
A55 6 HS100000 WASHER, NO. 10 NYLON
COUNTERSUNK FINISHING
ITEM QTY PART NO. DESCRIPTION
A56 4 HS307601 WASHER, FLAT .281 ID X .500 OD X
.062 T
A57 4 HS307602 WASHER FLAT .281 ID X 1.000 OD. X
.063 TH
A58 2 HS328300 LOCKWASHER SPLIT .312
A59 10 HS347700 WASHER, USS .375
A60 4 HS427100 WASHER, SPRG .760 1.000 .136
A61 2 HT512517 TAP SC 10-24 X 1.00 TYPE WB PN
HD PHIL BLK
A62 8 HT552512 PAN HD PHIL HD SELF TAPPING,
8-16 x .50 TYPE WB
A63 16 HT552515 PAN HD PHIL HD SELF TAPPING,
8-16 x .75, TYPE WB BLACK
A64 2 HT552516 PN HD PHIL SC # 8 X .875 BLK
A65 8 HT572512 TAP SC NO. 10-24 X .50 PN HD PHIL
A66 2 HX-16751 CAP, FRAME TUBE
A67 4 HX-17017 PLUG, TUBE END 1.50 TUBE OD
A68 2 HX-17023 PIN, SPRING .1875 x .75 LG, TYPE
420
A69 4 HX-17143 RING RETAINING, INTERNAL,
.500-168
A70 8 HX622815 SHCS .250-20 UNC-3A SS
A71 8 HX700415 BHSCS .375-16 X .75 SS, 620A ONLY
A71 24 HX700415 BHSCS .375-16 X .75 SS, 629A ONLY
A72 2 HX700417 BHSCS .375-16 X 1.00 SS
A73 4 JC700422 BHSCS .375-16 X 1.50
A74 2 JD623324 BOLT, SHOULDER .312 x 1.75
.250-20 UNC
A75 4 JS347400 LOCKWASHER, INT TOOTH .375
A76 1 MR-18446 MOTOR, ELEVATION, 12 VDC
A77 4 PL-16535 CAP, LINKAGE ROD, 2.00 OD
A78 1 PL-17209 WATER BOTTLE HOLDER
A79 4 PL-17279 SPACER, SHAFT, FOOT PLATE
A80 2 PP080202 INSERT, PLASTIC, 1.19 DIA-11 GA
A81 1 PP130003 INSERT, DOMED PLASTIC
A82 2 YD000026 TAPE, DOUBLE COATED 4” LONG
A83 1 619A-201 REAR LEG RH, 629A ONLY
A84 1 619A-202 REAR LEG LH, 629A ONLY
A85 1 AW-19521 POWER CORD 230 VAC (OPTIONAL)
A85 1 AW-19522 POWER CORD 115 VAC (OPTIONAL)
A85 1 AW-19587 POWER CORD 100 VAC (OPTIONAL)
A85 1 EW600005 POWER CORD 220 VAC (OPTIONAL)
A86 1 5620A-4 OWNER’S MANUAL (NOT SHOWN)
A87 1 610-349-4 WARNING DECAL
A88 1 DE-17218-4 HEART RATE ZONE DECAL
A89 2 DE-17219-4 CAUTION DECAL
A90 1 DE-19561 ETL LABEL
A91 1 DE-19592 SERVICE SCHEDULE & ERROR CODE
A92 1 DE-19547-4 DECAL, MEDICAL INLET
A93 1 610A-300 RIGHT FOOT PLATE (BLACK)
A93 1 610A-390 RIGHT FOOT PLATE (YELLOW)
A94 1 610A-301 LEFT FOOT PLATE (BLACK)
A94 1 610A-391 LEFT FOOT PLATE (YELLOW)
A95 2 610A-302 TOE CAP (BLACK)
A95 2 610A-392 TOE CAP (YELLOW)
A96 2 610A-100 CONTACT GRIP ASSY (BLACK)
A96 2 610A-123 CONTACT GRIP ASSY (YELLOW)
A97 2 610A-397 CAUTION DECAL (IFE OPTION ONLY)
A98 1 CM000240 WARNING DECAL
A99 1 620A-121 CONSOLE MOUNT
A100 4 HS307400 LOCKWASHER, INT TOOTH .250 SS
A101 4 HX620420 BHSCS .250-20 X 1.250 SS
A102 1 620A-122 CONSOLE MOUNT W/AV OPTION
ITEM QTY PART NO. DESCRIPTION
Customer
Service
Page 6-4
