CYBEX ATON 3S User Manual

36
NOTE! Do not twist the shoulder straps.
WARNING! The child seat must never be used
without the cover.
• Open the buckle.
• Remove the shoulder pads from the shoulder belts.
• Pull the headrest cover over the headrest rim.
• Pull the shoulder belts with the buckle tongues out of
the headrest cover.
• Remove the headrest cover.
• Pull the seat cover over the seat rim.
• Pull the buckle through the seat cover.
• Now you can remove the cover part.
REMOVING THE COVER
ATTACHING THE SEAT COVERS
The cover consists of 5 parts. 1 seat cover, 1 headrest
cover, 2 shoulder pads and 1 buckle pad. To remove the
cover please follow these steps:
in order to put the covers back onto the seat, proceed in
the reverse order as shown above.
NOTE! Use CYBEX ATON 3S covers only!

CYBEX ATON 3S Specifications

General

Product color	Charcoal
Car seat group	0+ (0 - 13 kg; 0 - 15 months)
Adjustable headrest	Yes

Weight and Dimensions

Depth	639 mm
Width	515 mm
Height	558 mm
Weight	4800 g
