Temperature
The unit is designed to function normally in an environment with an ambient temperature range of 50° F (10° C)
to 104° F (40° C). The unit can be shipped and stored in an environment with an ambient temperature range of 32°
F (0° C) to 140° F (60° C).
Verify parts list shown below
DiagramDescriptionPart NumberQty
Foot Pad 6.25” × 2.00”12090-3222
Foot Pad 5.00” × 2.00”13000-3532
Foot Pad13000-3541
Foot Pad13000-3551
Decal, Standard 80-100 (Included
with weight pack 13000-038)
DE0000071
Weight Plate (standard stack)
(Included with weight pack
13000-038)
4700-33716
Decal, Standard 5-75 (Included
with weight pack 13000-038)
DE0000061
8810 Chin Up Bar8810-1011
BHSCS .375-16 × 1.00 (Included
with 8810-101)
HC7004174
Page 10 of 27
