CYBEX BRAVO 8840 User Manual

13
Cybex Bravo 8830/8840 Owner’s Manual
If Then
If machine needs
weight stacks
removed before
moving to desired
location.
5. Repeat procedure for opposite guide rods.
6. Remove spiral pin securing cable end to top weight using a 3/16”
pin punch and hammer.
Top Weight
Connector
Roll
Pin
Pulley Bracket
Cable
7. Remove lifting post.
8. Remove weight plates
9. Move machine to desired position.
10. Remove the four shipping cones using a 3/4” socket or wrench.
11. Attach foot pads to each foot of frame.
Install weight plates
1. Install individual weight plates one at at time.
2. Position each weight plate so wide edges of bushings face upward and narrow edges
of bushings face downward.
CORRECT
Wide bushing
edge faces upward
The narrow bushing edge
must face downward.
WRONG
3. Install lifting post.
4. Snap guide rods into position.
