11
a)
a)
a)
With the locking pins facing you slide the
handle into recepticle.
Push in the locking pins and push handle in
until it makes an audible „click“.
Attention!
The pins on both sides must be fully
engaged.
Attention!
The Wheel system with the brake pedal must
be fitted to the right side of the
buggy (viewed from behind the buggy).
Attention!
The pins on both sides of the wheel system
must be fully engaged. Ensure the bowden
cable is inserted into the clips.
Fit the front wheels to the end of the frame
until they engage with a “click”.
2. ASSEMBLING THE HANDLES
3. ASSEMBLING THE FRONT WHEELS
4. ASSEMBLING THE REAR WHEELS
EN
