14
9. EXTENDABLE CANOPY
a)
1) Attach both outer canopy clips onto the inside of the outer
frame tubes of the buggy.
The middle canopy clip attaches from the front onto the top
middle frame tube of the buggy.
To remove the canopy reverse procedure.
2) Extend the canopy and place canopy rear flap behind the seat.
3) Lie-flat position: Put the rear flap over the seat’s back rest and
fixate it with the two velcros underneath.
8. AUTOMATIC FRONT WHEEL SWIVEL LOCKS
a)
1
2
1
3
2
1) Push the Front Swivel Lock Lever until it “clicks”. It can be
activated in any wheel position.The swivel Lock will engage
automatically once the wheel swivels into the correct position.
2) Lift the Front Swivel Lock Lever up again to release the Swivel
Lock.
