Cybex VR3 12180 Tricep Press Owner’s Manual
Assembly
Page 4-1
4 - Assembly
TOOLS REQUIRED
7/32” Allen wrench•
1/8” Allen wrench •
Medium weight automotive engine oil•
Torque wrench•
3/4” Wrench•
NOTE: Two people will be required for this procedure.
NOTE: It is the responsibility of the facility owner/owner of the equipment to ensure that there
is appropriate clearance around each machine to allow for safe use and passage.
NOTE: Refer to chapter 6 for reference diagrams.
1. Read and understand all instructions thoroughly before starting any of
the procedures listed on this instruction sheet.
2. Verify you have received the appropriate confi guration.
Verify that you received the correct color machine that you ordered.A.
Verify you received the proper weight stack.B.
Verify you received the appropriate owner’s manual. C.
Verify you received the warranty sheet.D.
Verify you received the weight stack decals.E.
3. Move to desired location.
4. Remove shipping feet.
WARNING: Use extreme caution when removing shipping cones and installing feet.
Failure to do so could result in injury.
With an assistant, carefully remove each (standard) cone-shaped shipping support A.
using a 3/4” socket or wrench.
Cut shipping tie securing top weight.B.
Carefully place rubber feet (supplied with machine) on each foot of the frame.C.
5. Installing the weight stack.
If weight stack is already installed, proceed to step 9.A.
Using a 1/8” Allen wrench, remove the two Button Head Socket Cap Screws (BHSCS) securing the B.
bottom bracket to the frame. NOTE: Do not remove middle BHSCS securing shroud to bottom bracket.
Remove the remaining BHSCS securing the back shroud to the frame. C. NOTE: After fi nal BHSCS
is removed shroud will slide down to the fl oor with bottom support bracket attached.
Carefully slide shroud out of machine.D.
