PHOTON USER MANUAL
TECHNICAL SPECFICIATIONS
Description
This product is a high-powered electric bike (ebike) drive unit kit which includes a programmed
control unit and peripherals. This product is designed to be installed as a conversion system to
convert standard bicycles into electric bicycles.
General
Rated Voltage
36V – 52V
Max. RPM at Crank
>300 RPM
Rated Power
250W / 750W
Max. Torque at Crank
110 N.m.
Colour
Anodized Black
Weight of Motor Uni
3.2 kg
Total Weight with Crank set & BB
4.5 kg
Bracket Materials
7075-T6
Crank Arm Length
165mm or 175mm
Control Method
FOC
Motor Sensor
Hall & Temp. Sensor
Chain ring
34T / 38T / 42T / 50T
Compatibility
68-83mm, 100mm, 120mm BSA Threaded
>121mm Pressfit (with adapter)
*Bottom brackets not specified may be compatible. Contact CYC MOTOR LTD for more information
before making a purchase if your bottom bracket is not listed above.
