System Overview cont.
SSYYSSTTEEMM IINNSSTTAALLLLAATTIIOONN
11.. IInnsseerrtt WWhheeeell IInnttoo FFrraammee
Insert the PowerTap SL2.4 wheel into the frame. Make sure the
axel is correctly positioned in the dropouts and secure the
wheel in place with a steel skewer.
22.. AAttttaacchh CCoommppuutteerr SShhooee ttoo HHaannddlleebbaarr oorr SStteemm
The shoe can be mounted on either the handlebar or stem. Secure the receiver shoe with cable
ties. Slide the receiver shoe in the direction of the arrow as depicted in either FIGURE 2A or 2B
depending on mounting location.
Receiver Shoe
Mounting Base
Arrow
Receiver Shoe
Mounting Base
Arrow
Slide shoe in direction of arrow onto the base.
Slide shoe in direction of arrow onto the base.
22AA.. AAttttaacchh RReecceeiivveerr mmoouunntt ttoo HHaannddlleebbaarr
22BB.. AAttttaacchh RReecceeiivveerr mmoouunntt ttoo SStteemm
