Attaching the Trailer to a Bike
1. Remove the quick release or nut from the left side of the bikes rear axle. Install the hitch connector
between the quick release or nut and the bike frame. Tighten the quick release or nut according to the
manufacturers recommendation.
2. Insert the flex connector onto the hitch connector. Insert the lock pin and close the spring clip. Wrap
the safety strap around the frame of the bike and latch to the D-ring on the tow bar.
WARNING! Safety strap must attach to the bike frame when using this product in trailer mode.
Quick -release lock pin must be in place and locked before riding.
The height of the hitch clamp shall not exceed 15.7in (400mm) above the road surface and the stan-
dard drawbar load shall be between 30 and 80N.
1
2
3
4
10
