CYCLIC Switcharoo Series - Securing the Tow;Pull Arm

Securing the Tow/Pull Arm
1. Attach the kick-stand by inserting the stand into the end of the tow arm until the spring-pin engages.
(fig 1)
2. Attach the tow arm onto the trailer frame as shown and secure with the lock-pin (fig 2 and fig 3)
WARNING! Check this pin periodically during and before each use to be sure it has not become
loose. Failure to do so could result in serious injury.
7
2
1
3
