Configuring as a Wagon
1. If the vehicle is in trailer mode, unscrew the large screw knob at the tow arm anchor.
2. Rotate the tow arm 45 degrees upwards and align the screw knob through-hole.
3. Seure the arm in place by fastening into place using the large screw-knob.
Check this pin periodically during and before each use to be sure it has not become loose. Failure to
do so could result in serious injury.
13
