Assembling your Trailer
1. Remove the trailer parts from the box. Set the main trailer body flat on the ground with the black side
down.
2. Lift the side wall up (fig 1) and repeat witht the opposite side (fig 2).
3. Swing the cross arms into place an locate onto the frame to align with the through hole on the
frame. (fig 3)
4. Secure the cross arms with the two screw-knobs as shown. Fasten until hand tight. (fig 4)
5. Secure the front and rear fabric walls onto the crossbars with the velcro tabs.
WARNING! Immediately discard of all plastic bags and plastic wrapping materials.
5
1
3
2
4
