MOUNTING FLY6 WITH
AERO POST (STEM)
1 — Slide seat post mount onto your Fly6
until you hear a ‘click’
2 — Select the appropriate alignment
spacer that aligns your Fly6
perpendicular to the ground
3 — Peel off backing from adhesive tape to
afx selected spacer to seat post mount
4 — Attach provided straps to
seat post mount
5 — Fit aero spacer onto seat post
6 — Hold unit onto seat post (stem) and
wrap straps around to fasten
Click
WWW.CYCLIQ.COM 21
