5. Specifications
Content
Specification
DIM
9.6×5.3×1.6cm
Weight
70g
Network
GSM/GPRS
Band
850/900/1800/1900Mhz
GPS sensitivity
-159dBm
GPS accuracy
5m
GPS start time
Cold status 45s
Warm status 35s
Hot status 1s
Car power
supply
12 V -24V
Back up battery
Chargeable 3.7V 700mAh Li-ion battery
Storage Temp
-40°C to +85 °C
Operation
Temp.
-20°C to +65°C
Humidity
5%--95% non-condensing
6. Terminal Installation
Terminal Installation
Please ask the qualified engineers to install it.
Do not install it in an environment which is over GSM performance index.
Pay attention to make installation location preventing water and dust.
Find the 12 PIN harness and insert it into the corresponding holes of the products, and connect the
wires with the original car circuit showing below:
