CYP XA-1 User Manual

7
9. OLED
96k 2CH ARC
1080P@60
H:1920 3DTB
1
5
2
3
4
6
1
. Sampling Rate: The device support audio sampling rate of 48/96/192KHz
and the OLED will display it according to the selection, if external audio is
selected the OLED will display bypass.
2
. Audio Channels: The device support audio channels from LPCM 2, 5.1
and 7.1CH, if external audio is selected the OLED will display bypass.
3
. ARC: Audio Return Channel, when the function is selected the OLED will
display ARC if not, the OLED will not illuminate ARC.
4
. Timing Frequency & V Sync : Please referes to section 10. Timing Table for
the supports timing and V sync details.
5
. H Sync: Please referes to section 10. Timing Table for the supports H sync
details.
6
. 3D PATTERN: Only when the 3D pattern is selected, the OLED will show
the patter details.
10. Timing Table
No. Resolution V Hz No. Resolution V Hz
T01
T02
T03
T04
T05
T06
T07
T08
T09
T10
T11
T12
T13
480p
480i
720P
1080i
1080p
576i
576p
720p
1080i
1080p
1080p
640x480
800x600
60
60
60
60
60
50
50
50
50
50
24
60
60
T14
T15
T16
T17
T18
T19
T20
T21
T22
T23
T24
T25
1024x768
1280x1024
1920x1200
720p (3D Frame Packing)
720p (3D Side-by-Side)
720p (3D Top-to-Bottom)
720p (3D Frame Packing)
720p (3D Side-by-Side)
720p (3D Top-to-Bottom)
1080p (3D Frame Packing)
1080p (3D Side-by-Side)
1080p (3D Top-to-Bottom)
60
60
60
60
60
60
50
50
50
24
24
24
