8
11. Support Pattern Table
GROUP NO. PATTERN Description
Standard Type
1
Primary colors: Red, Green,
Blue
P1: Red
P2: Green
P3: Blue
2
3
4
P4: Horizontal RGB Bar
5
P5: H Grey Scale
6
P6: HDCP handshaking and
link-integrity test
