1. Introduction
The 3D mini HDMI Analyzer is a tool for checking both source and display
devices. With touch button control and built-in OLED (Organic Light Emitting
Diode) it can show status of both input and output device. The major purpose
is to analyze input source info-frame and output sink EDID. Another purpose is
to use built-in pattern to test output device.
2. Applications
• Apparatus testing
• Equipment adjustment
• EDID checking
•
• Production testing
• RD design
3. Package Contents
• 3D Mini HDMI Analyzer
• Operation Manual
• 5V Power Adaptor
4. System Requirements
HDMI input port connected to the source/HDMI system with HDMI port and
output connected to the display/HDMI system with HDMI port.
5. Features
• Supports Timing include SD, HD up to 1080p, PC up to WUXGA and 3D
• Provides 25 timings, 6 patterns and 1 pattern for 3D timing
• Deep color video up to 12 bits, 1080p@60Hz
• Support input signal bypass, digital video formats in Deep Color Mode at
up to 36 bits (12 bits/color) and new lossless compressed (Dolby TrueHD,
Dolby Digital Plus and DTS-HD master Audio) digital audio
• Supports internal pattern audio LPCM 2CH 48/96/192KHz, LPCM 5.1CH
48/96KHz, LPCM 7.1CH 48/96KHz. LPCM 2CH has a single-tone sound;
LPCM 5.1CH has a dual-tone sound; LPCM 7.1CH has a tri-tone sound. To
confirm whether you are receiving 5.1 or 7.1, listen for the dual and tri-tone
audio from the device.
•
Analyze input source info-frame and output sink EDID
•
Touch button control function
•
OLED show Input / Output timing information
•
