16. Colourbar S.
The Colourbar S. pattern is a standard SMPTE colour bar pattern which is
used for rapid verification of signal colour accuracy and for display setup
using the Blue-Only option on your display, if it has one.
17. Colourbar Split
The Colourbar Split pattern is a vertical colour bar pattern with the
colour bars split in the middle by large black and white sections. All
colours (white, yellow, cyan, green, magenta, red, blue) are at 100%
brightness.
18. Colourbar-V (3 variations)
100% 75% 100% & 75%
The Colourbar-V pattern comes in 3 variations. The first is a standard
(white, yellow, cyan, green, magenta, red, blue, black) 100% colour
bar pattern using vertical bars. The 2nd variation has all bars at 75%
brightness. The 3rd variation is split with the top half being at 100% and
the lower half being at 75% brightness.
