43
pattern.
48. Square H8 (2 variations)
Normal Inverse
The Square H8 pattern is a full field black & white pattern of squares
dividing the screen horizontally into 8 sections. This pattern is primarily
used to check projector linearity. There are 2 variations: Normal (white
lines, black field) and Inverse (black lines, white field).
49. Square H16 (2 variations)
Normal Inverse
The Square H16 pattern is a full field black & white pattern of squares
dividing the screen horizontally into 16 sections. This pattern is primarily
used to check projector linearity. There are 2 variations: Normal (white
lines, black field) and Inverse (black lines, white field).
50. Square H32 (2 variations)
Normal Inverse
The Square H32 pattern is a full field black & white pattern of squares
dividing the screen horizontally into 32 sections. This pattern is primarily
used to check projector linearity. There are 2 variations: Normal (white
lines, black field) and Inverse (black lines, white field).
