CYRUS CD6s PCB PARTS LIST
© Cyrus Audio Ltd Nov 2006 23 Cyrus CD6s Service Manual Issue 2
C628 SMD0603 NOT FITTED
C629 SMD0603 10nF CP 50V 10%
C630 SMD0603 10nF CP 50V 10%
C631 SMD0603 NOT FITTED
C632 SMD0603 NOT FITTED
C633 SMD0603 10nF CP 50V 10%
C634 SMD0603 NOT FITTED
C635 SMD0603 NOT FITTED
C636 SMD0603 NOT FITTED
C637 SMD0603 NOT FITTED
C638 SMD0603 NOT FITTED
C639 SMD0603 10nF CP 50V 10%
C640 SMD0603 10nF CP 50V 10%
C641 SMD0603 10nF CP 50V 10%
C642 SMD0603 NOT FITTED
C643 RB.3/.7 2200uF EL 25V 20%
C644 RB.2/.5 1200uF EL 16V 20%
C645 CAPSMD5.0 22uF EL 16V 20%
C646 RB.3/.7 2200uF EL 25V 20%
C647 RB.3/.7 4700uF EL 25V 20%
C648 RB.3/.7 4700uF EL 25V 20%
C649 RB.3/.7 NOT FITTED
C650 RB.3/.7 NOT FITTED
C651 CAPSMD6.3 47uF EL 16V 20%
C652 CAPSMD6.3 47uF EL 16V 20%
C653 CAPSMD6.3 220uF EL 16V 20%
C654 CAPSMD6.3 47uF EL 16V 20%
C655 CAPSMD6.3 47uF EL 16V 20%
C656 CAPSMD6.3 47uF EL 16V 20%
C657 CAPSMD6.3 220uF EL 16V 20%
C659 CAPSMD5.0 22uF EL 16V 20%
C661 CAPSMD5.0 47uF EL 6.3V 20%
C662 CAPSMD5.0 NOT FITTED
C663 CAPSMD5.0 NOT FITTED
C664 RB.3/.7 4700uF EL 25V 20%
C665 SMD0603 10nF CP 50V 10%
C666 SMD0603 10nF CP 50V 10%
Key:
CP = ceramic plate. EL = electrolytic. PE = polyester. PP = polypropylene. BP = bi-polar.
CAPSMD6.3 refers to surface mount device with 6.3mm pitch pads
SMD-0805 refers to surface mount device size code 0805
DIODES
D501 SOT-23 BAV99 300mA Dual Signal Diode
D502 SOT-23 BAV99 300mA Dual Signal Diode
D503 SOT-23 BAS16 300mA Signal Diode
D505 SOT-23 5V6 BZX84C5V6 5V6 Zener Diode
D506 PSM 1SR154-400 1A Rectifier Diode
D507 PSM 1SR154-400 1A Rectifier Diode
D508 SOT-23 BAW56 300mA Dual Signal Diode
D601 PSM NOT FITTED
D602 PSM 1SR154-400 1A Rectifier Diode
D603 PSM 1SR154-400 1A Rectifier Diode
D604 DIODEBR2-SM DF02 1A Rectifier diode bridge
