CYRUS CD6s PCB PARTS LIST
© Cyrus Audio Ltd Nov 2006 24 Cyrus CD6s Service Manual Issue2
D605 SOT-23 11V BZX84C11V 11V Zener Diode
D606 SMC deleted
D607 DIODEBR2-SM DF02 1A Rectifier diode bridge
D608 DIODEBR2-SM NOT FITTED
TRANSISTORS
T101 SOT-23 BC817-25 NPN Signal Transistor
T102 SOT-23 BC817-25 NPN Signal Transistor
T501 SOT-23 BC807-25 PNP Dual Signal Transistor
T502 DPAK1 MJD32C PNP SMD Power Transistor
T503 SOT-23 BC817-25 NPN Dual Signal Transistor
T504 SOT-23 BC817-25 NPN Dual Signal Transistor
T505 SOT-23 DTA114YK PNP Digital Transistor
T506 SOT-23 DTA114YK PNP Digital Transistor
T507 SOT-23 DTA114YK PNP Digital Transistor
T601 TO-220 TIP31 NPN Power Transistor
T602 SOT-23 BC817-25 NPN Signal Transistor
T603 SOT-23 NOT FITTED
INTEGRATED CIRCUITS
IC101 VSOP24 AK4103 Digital Audio Output Encoder
IC201 SO-14 74HCT86 Quad XOR
IC202 SOL-20 74HC574 Octal Latch
IC203 SO-14 74HC14 Hex Schmitt Inverter
IC204 SO-16 CD74HC4046AM PLL and VCO NO ALTERNATIVE
IC205 SO-16 74HC161 8 Bit Shift Register
IC206 SO-14 74HC74 Dual D type Flip Flop
IC301 SSOP28 PCM1738 24 bit 192kHz DAC
IC302 SO-8 BA15532 Low noise dual op amp
IC303 SO-8 BA15532 Low noise dual op amp
IC304 SO-8 BA15532 Low noise dual op amp
IC305 SO-8 NOT FITTED
IC401 SSOP28 NOT FITTED
IC402 SO-8 NOT FITTED
IC403 SO-8 NOT FITTED
IC404 SO-8 NOT FITTED
IC501 SO-14 74HC14 Hex Schmitt Inverter
IC502 QFP-64SKT H8/3644 8 bit Microcontroller
IC503 SOT-23-GEC DS1811R-15 Reset control IC
VOLTAGE REGULATORS
VR301 SOT223 REG1117A
800mA +VE Adjustable Regulator
VR401 SOT223 NOT FITTED
VR601 SOT252 LM1117DT-5.0 800mA +VE Regulator SMD
VR602 TO220 LM2940CT-5.0 1A +VE 5V regulator LDO
VR603 TO220 LM317 1A +VE Adjustable Regulator
VR604 SOT223 REG1117A
800mA +VE Adjustable Regulator
VR605 SOT223 NOT FITTED
VR606 TO220 LM337 1A -VE adjustable regulator
