CYRUS CD6s PCB PARTS LIST
© Cyrus Audio Ltd Nov 2006 25 Cyrus CD6s Service Manual Issue 2
FILTERS , INDUCTORS & CRYSTALS
L101 COIL7KM NOT FITTED
L201 1206 1uH FSLM2520
L601 1206 1uH FSLM2520
L602 COIL-DO3316 deleted
X501 XTAL SMD 9.8304MHz 4HSMX SMD Xtal, Alt IQD
XTAL201 XTALMODULE14 NOT FITTED
CONNECTORS AND SOCKETS
CON101 CONLIF12S 00-8370-127-000-800
12 Way flex foil side entry 1.25mm
CON102
9 way cable 9way Molex KK header to 9 way JST
CON103
4 way cable 4 way Molex KK header to 4 way JST
CON104 CONZIF12S 39-51-3123
12 Way flex foil side entry 1.25mm
CON105 CONLIF12S 00-8370-127-000-800
12 Way flex foil side entry 1.25mm
CON106 2.8mmQC DNF
CON107 2.8mmQC RMB6199 2.8x 0.5mm rt angle quick connect
CON108 2.8mmQC RMB6199 2.8x 0.5mm rt angle quick connect
CON109 2.8mmQC DNF
CON501 CON-RJ45-SMD 98435-511 Alt 85513-0013
CON601 CONMINIPWR6 6 way Alt 39-31-0060
CON602 CONMINIPWR6 NOT FITTED
CON603 CON-PSX NOT FITTED
SK101 PHONOQUAD Quad Phono Gold plated, black sockets
SK103 Black RCA NOT FITTED
SK501 PHONODUAL Dual Phono Gold plated, black sockets
OTHER PARTS
TOTX101 TOX179 Optical output
