2.2 Ground End Power Supply System
Transportation mode
Operating mode
Manual handle of
retracting the cable
Open the metal handle to
manually retract the cable
Handle
Carry with one hand
TYPE-C socket for
battery connection
Near field lighting
system
Cable viewing port
czi logo
High voltage cable outlet
Triple-proof design of
output ports
Main power On / Off
Three-proof design
Power supply heat dissipation air inlet
Double-layer design
Power supply socket
Near field lighting system
High voltage cable outlet
Operating panel
Main power switch
Manual handle of
retracting the cable
Quick release stand
Extendable support rod
TYPE-C socket for
battery connection
Drone battery
