TK3 ground end
TK3-M350 drone end
Overall
dimensions
Overall
dimensions
Weight
Power
Rated Input
Voltage
Rated output
voltage
Main rated
output current
356mm*310mm*229mm
165.6mm*90.9mm*68.9mm
566 g ± 5%
Rated 3.0 kw
260-410 VDC
36.5-52.5 VDC
60 A
Weight 7.5 kg ± 5%
Power
≥ 3000 W (176Vac-264Vac input); ≥ 1500 W（90Vac-175Vac
input）
Cable
80m cable
Cable diameter less than 2.8mm, over-current capacity greater
than 10 A, weight less than 1.2 kg / hundred meter, tensile
strength greater than 20 kg, withstand voltage 600 V, internal
resistance less than 3.6Ω/100m@20℃
Rated Input
Voltage
90-264 VAC+10%
Rated operating
frequency
50/60 Hz
Output voltage 400 VDC
2.4 Equipment Parameters
