D.A.C.E Compact 300 User Manual

2
General info rmation …………………………….3.
Safety instructions ………………………………4.
Terms and definitions …………………………...5.
General motor layout ……………………………6.
General site layout ………………………………7.
Site evaluation …………………………………...8.
Gate evaluation …………………………………..9.
Removing the lid and manual over ride …..…….10.
P.C.Board layout ………………………………..11.
Electrical wiring …………………………………12 / 13.
Anchoring the motor …………………………….14 / 15.
Mounting the rack / magnet ……………………..16.
Setting the motor direction ……………...……….17.
Programming the motor …………………………17 / 18.
Setting the over current …………………………18.
Programming the remotes ……………………….19.
Auto-close / multi-user / party mode ……………20.
Connecting infra-red beams ……………………..21.
Connecting an intercom …………………………22.
Connecting a receiver…………………………… 23.
Connecting a loop detector ……………………...24.
L.E.D. indications ……………………………….25.
External L.E.D. ………………………………….26.
Warranty …………………………………………26.
Speci fications ……………………………………27.
Installers details…………………………………..27.
INDEX
27
COMPACT 500 COMPACT 300
Intended use Domestic Dom estic
Max gate m ass 500 kg 300 kg
Max gate length 8m 8m
Max num ber of operations per day 50 40
Max start—up force 10 kg 6 kg
Gate speed 18 m / min 18 m / min
Electric m otor 120 watt 12 V D/C 120 watt 12 V D/C
Over-current sensing Electronic Electronic
Auxiliary out-put 12v D/C 12 v D/C
Charge rate 13.8 v D/C 13.8 v D/C
Receiver On board max 15 remotes On board max 15 rem otes
Transformer Fly lead 220V/AC Plug in 220 V/AC
Positive close Optional Preset
Auto-close Optional (10—70 seconds) Optional (10—70 seconds)
SPECIFICATIONS
Installers details
INSTALLER NAME…………………………………………………………………………..
INSTALLER CONTACT DETAILS………………………………………………………….
DATE OF INSTALLATION…………………………………………………………………..
COMPANY STAMP
