10BASE-T Ethernet Mini Hubs User’s Guide
Installation 11
Cascading Hubs Through Thin
Coaxial Cable
The BNC port on the Mini Hub model DE-809TC can be used to
cascade hubs together. You may cascade DE-809TC hubs together
through the BNC ports. You may also cascade the DE-809TC with
any other IEEE 802.3 Ethernet standard 10BASE-T hubs equipped
with BNC ports.
You may attach up to thirty nodes to a thin coaxial segment. In this
sense, it is possible to cascade a maximum of thirty hubs together
through the thin coaxial cable.
Be sure to leave a minimum of 0.5 meter (2 feet) of cable between
two BNC ports.
