10BASE-T Ethernet Mini Hubs User’s Guide
Cables, Connectors & AC Power Adapters 17
A
Cables, Connectors &
AC Power Adapters
10BASE-T Unshielded Twisted-Pair
(UTP) Cable
♦
Cable characteristics: 0.4 - 0.6 mm (22 - 26 AWG) 8-wire
(only 4 wires used for 10BASE-T)
♦
Maximum segment length: 100 meters
♦
Applicable connectors: RJ-45, Telco-50
10BASE2 Thin Coaxial Cable
♦
Cable characteristics: 0.2 inch diameter RG-58A/U 50 ohm
♦
Maximum segment length: 185 meters
♦
Minimum distance between two nodes: 0.5 meter
♦
Maximum number of nodes per segment: 30
