Connecting The DI-614+ Wireless Router
To Your Network
A. First, connect the power adapter to the receptor at the back panel of
the DI-614+ and then plug the other end of the power adapter to a wall
outlet or power strip. The Power LED will turn ON to indicate proper
operation.
B. Insert one end of an Ethernet cable to the WAN port on the back
panel of the DI-614+ and the other end to the Ethernet port located on
your Cable or DSL modem. The WAN LED light will illuminate to
indicate proper connection.
C. Insert an Ethernet cable to LAN port 1 on the back panel of the DI-
614+ and an available Ethernet port on the network adapter in the
computer you will use to configure the DI-614+. The LED light for LAN
Port 1 will illuminate to indicate proper connection. (Note: Some
computers already have network adapters pre-installed.)
D. Computers equipped with 802.11b wireless adapters will be able to
connect to the DI-614+. The DWL-650+ AirPlus Wireless Cardbus
Adapter and the DWL-520+ AirPlus Wireless PCI Adapter will be able
to connect out of the box with the router using their default wireless
settings.
Restart Your Computer
Reset Button
Pressing this button restores
the router to its original factory
default settings.
A. Receptor for
Power Ada
