Connecting Additional Computers To The
DI-614+ Wireless Router
Using additional Ethernet (CAT5 UTP) cables, connect your Ethernet-
equipped computers to the remaining Ethernet LAN ports on the back
panel of the DI-614+.
When you have completed the steps in this Quick Installation Guide, your
connected network should look similar to this:
M1 LED – a
solid light
indicates that
the DI-614+ is
ready.
WAN LED – a
solid light indicates
connection on the
WAN port. This
LED blinks during
data transmission.
POWER LED – a
solid light indicates a
proper connection to
the power supply.
WLAN LED – a solid
light indicates that the
wireless segment is
ready. This LED
blinks during wireless
data transmission.
LOCAL NETWORK
LEDs – a solid light
on the port indicates a
connection to an
Ethernet enabled
computer on ports 1-4.
This LED blinks during
data transmission.
M2 LED
– A solid light indicates
that the unit is defective.
