D-Link AirPlus DP-G321 - Page 2

2
Connecting the DP-G321 to Your Network
USB Ports: Used to
connect USB printers.
Power Receptor:
Connects the AC
Power Adapter
LAN Port: Connects
to a router or switch.
Warning!
Only attach USB printers to the USB ports of the DP-G321. Do not connect any other USB device
to the DP-G321’s USB port! Other devices may damage the unit and void the warranty.
Antenna: Used to wirelessly
connect to 802.11b/g adapters.
LPT Port: Used to
connect a standard
parallel printer.
