D-Link COVR-C1203 Quick Installation Guide

3
ENGLISH
ENJOY!
You’re all good to go! Connect devices to your network using the
Wi-Fi Name (SSID) and password that you created during the setup
process.
Connect your computer to the Wi-Fi name and password printed
on the Quick Installation Card, or on the device label on the bottom
of the device.
Type http://covr.local./ into the address bar of a web browser.
Follow the on-screen instructions to complete the setup.
4 /
Wait for the 2.4 GHz and 5 GHz wireless LEDs to turn on.
Note: If your router does not have 2.4 and 5G wireless LEDs, refer to
the User Manual for LED behaviour.
5 /
6 /
http://covr.local./
I
2.4 5G

D-Link COVR-C1203 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Internal	No
Placement	Floor, Table
Certification	FCC, CE, IC, RCM, IDA, CB, RoHS, UL, ErP
Product color	Bronze, White
LED indicators	Status
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	128-bit AES, WPA, WPA2
Antenna features	Integrated antenna
Antennas quantity	3
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	3.5 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Number of products included	3 pc(s)
Package depth	313 mm
Package width	246 mm
Package height	115 mm
Package weight	1780 g
Pallet width	1100 mm
Pallet length	1200 mm
Pallet height (air)	1243 mm
Pallet height (sea)	2074 mm
Pallet gross weight (air)	235600 g
Pallet gross weight (sea)	401100 g
Quantity per pallet (air)	112 pc(s)
Quantity per pallet (sea)	196 pc(s)
Shipping (inner) case width	330 mm
Shipping (inner) case height	277 mm
Shipping (inner) case length	486 mm
Shipping (inner) case weight	7880 g
Shipping (inner) case net weight	7120 g
Number of cartons per pallet (air)	28 pc(s)
Number of cartons per pallet (sea)	49 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Depth	109 mm
Width	117 mm
Height	51 mm
Weight	250 g
