6D-Link COVR-1102 User Manual
Section 1 - Product Overview
COVR-1100 Rear Panel
1 Power Button Press the power button to power the device on or o.
2 Internet WAN Port Using an Ethernet cable, connect your broadband modem to this port.
3 Ethernet LAN Port Connect Ethernet devices such as computers, switches, storage (NAS) devices, and game consoles.
4 Power Connector Connect the included power adapter here to power on the device.
5 Reset Button Insert a paperclip in the hole, wait for 5 seconds, then release to reset the router to default settings.
1 2 3 4 5
