D-Link Covr User Manual

10D-Link COVR-1102 User Manual
Section 3 - Conguration
Conguration
When prompted, enter your password. If you previously followed the setup
wizard, please use the admin password you entered during the wizard.
Otherwise, leave the password blank. Click Log In to proceed.
Note: If you cannot remember your password and cannot log in, press the
Reset button on the bottom of the device with an unfolded paper clip to
restore the device to its default settings. Refer to Resetting your Device on
page 79 for more information.
To access the web conguration utility, open a web browser such as Internet
Explorer and enter http://covr.local./ in the address bar.
If you want to access the web interface using a wireless connection, connect
to your COVR Wi-Fi, then open a web browser such as Internet Explorer and
enter http://covr.local./ in the address bar.
Note: If you have previously changed the Management Link in the Network
settings, use this link to access the web user interface instead.
When you are logged in, the device's home page will open, displaying its
current connection status.
The bar at the top of the page has quick access to Settings , Features, and
Management functions. You may quickly jump back Home at any time.
Note: The system will automatically log out after a period of inactivity.

D-Link Covr Specifications

General

Internal	No
Placement	Floor, Table
Certification	FCC, CE, IC, RCM, IDA, CB, RoHS, UL, ErP
Product color	Bronze, White
LED indicators	Status
WPS push button	Yes
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
MIMO type	Multi User MIMO
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Antenna features	Integrated antenna
Antennas quantity	3
Security algorithms	128-bit AES, WPA, WPA2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	3.5 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Number of products included	2 pc(s)
Package depth	274 mm
Package width	208 mm
Package height	118 mm
Package weight	1270 g
Pallet width	1100 mm
Pallet length	1200 mm
Pallet height (air)	1335 mm
Pallet height (sea)	2055 mm
Pallet gross weight (air)	237200 g
Pallet gross weight (sea)	370500 g
Quantity per pallet (air)	160 pc(s)
Quantity per pallet (sea)	256 pc(s)
Shipping (inner) case width	495 mm
Shipping (inner) case height	240 mm
Shipping (inner) case length	575 mm
Shipping (inner) case weight	11110 g
Shipping (inner) case net weight	10160 g
Number of cartons per pallet (air)	20 pc(s)
Number of cartons per pallet (sea)	32 pc(s)
Quantity per shipping (inner) case	8 pc(s)

Weight and Dimensions

Depth	109 mm
Width	117 mm
Height	51 mm
Weight	250 g
