D-Link Covr User Manual

9D-Link COVR-1102 User Manual
Section 2 - Installation
Web Based Installation
Step 1
Position the COVR Point close to your Internet-connected modem. Next,
connect the power adapter and plug the COVR Point into a power outlet.
Step 2
Wait for the COVR Point to boot up. When the Status LED starts blinking
orange, wirelessly connect your computer to the Wi-Fi name (SSID) printed
on the back of the device, or on the included Quick Install Card.
Wi-Fi
Wi-Fi
Your AC1200 Dual Band Whole Home Mesh Wi-Fi System is now set up and ready to use. You can now congure your COVR Wi-
Fi settings using the free D-Link Wi-Fi mobile app or the web-based user interface. Refer to the Conguration section on page
10 for more information on conguring your network using the web-based user interface.
http://covr.local./
Step 3
Type http://covr.local./ into a web browser and follow the on-screen
instructions to complete the setup.
INTERNE TE THERNE TPOWER
12V
1A
SSID:
Password:
If you do not wish to use the D-Link Wi-Fi app, you can manually set up your Covr device and congure your Covr Wi-Fi network
using the web-based user interface.

D-Link Covr Specifications

General

Internal	No
Placement	Floor, Table
Certification	FCC, CE, IC, RCM, IDA, CB, RoHS, UL, ErP
Product color	Bronze, White
LED indicators	Status
WPS push button	Yes
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
MIMO type	Multi User MIMO
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Antenna features	Integrated antenna
Antennas quantity	3
Security algorithms	128-bit AES, WPA, WPA2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	3.5 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Number of products included	2 pc(s)
Package depth	274 mm
Package width	208 mm
Package height	118 mm
Package weight	1270 g
Pallet width	1100 mm
Pallet length	1200 mm
Pallet height (air)	1335 mm
Pallet height (sea)	2055 mm
Pallet gross weight (air)	237200 g
Pallet gross weight (sea)	370500 g
Quantity per pallet (air)	160 pc(s)
Quantity per pallet (sea)	256 pc(s)
Shipping (inner) case width	495 mm
Shipping (inner) case height	240 mm
Shipping (inner) case length	575 mm
Shipping (inner) case weight	11110 g
Shipping (inner) case net weight	10160 g
Number of cartons per pallet (air)	20 pc(s)
Number of cartons per pallet (sea)	32 pc(s)
Quantity per shipping (inner) case	8 pc(s)

Weight and Dimensions

Depth	109 mm
Width	117 mm
Height	51 mm
Weight	250 g
