D-Link Covr User Manual

18D-Link COVR-1102 User Manual
Section 3 - Conguration
Dynamic IP (DHCP)
Select Dynamic IP (DHCP) to obtain IP address information automatically from your Internet Service Provider (ISP). Select this
option if your ISP does not specify an IP address to use.
Advanced Settings
Host Name: The host name is optional but may be required by some ISPs. Leave
it blank if you are not sure.
Primary DNS
Server:
Enter the primary DNS server IP address assigned by your ISP. This
address is usually obtained automatically from your ISP.
Secondary DNS
Server:
Enter the secondary DNS server IP address assigned by your ISP. This
address is usually obtained automatically from your ISP.
MTU: Maximum Transmission Unit - you may need to change the MTU for
optimal performance with your ISP.
MAC Address
Clone:
The default MAC address is set to the physical interface MAC address
of port 1 on the master COVR Point. You can use the drop-down menu
to replace the Internet port’s MAC address with the MAC address of
a connected client.
Click Save when you are done.

D-Link Covr Specifications

General

Internal	No
Placement	Floor, Table
Certification	FCC, CE, IC, RCM, IDA, CB, RoHS, UL, ErP
Product color	Bronze, White
LED indicators	Status
WPS push button	Yes
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
MIMO type	Multi User MIMO
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Antenna features	Integrated antenna
Antennas quantity	3
Security algorithms	128-bit AES, WPA, WPA2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	3.5 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Number of products included	2 pc(s)
Package depth	274 mm
Package width	208 mm
Package height	118 mm
Package weight	1270 g
Pallet width	1100 mm
Pallet length	1200 mm
Pallet height (air)	1335 mm
Pallet height (sea)	2055 mm
Pallet gross weight (air)	237200 g
Pallet gross weight (sea)	370500 g
Quantity per pallet (air)	160 pc(s)
Quantity per pallet (sea)	256 pc(s)
Shipping (inner) case width	495 mm
Shipping (inner) case height	240 mm
Shipping (inner) case length	575 mm
Shipping (inner) case weight	11110 g
Shipping (inner) case net weight	10160 g
Number of cartons per pallet (air)	20 pc(s)
Number of cartons per pallet (sea)	32 pc(s)
Quantity per shipping (inner) case	8 pc(s)

Weight and Dimensions

Depth	109 mm
Width	117 mm
Height	51 mm
Weight	250 g
