D-Link DAP-1325 Quick Install Guide

DAP-1325 Install Guide 15
Where should I place my DAP-1325 when using it as a range extender?
A Range Extender only works as well as the signal it is extending. Therefore, proper
placement of your DAP-1325 is important in achieving desired results.
A Range Extender only works as well as the signal it is extending.
Therefore, proper placement of your DAP-1325 is important in
achieving desired results.
For best performance, place your DAP-1325 in between your
router and your dead zone, making sure it is placed in a location
where the Wi-Fi signal is still strong. Use the Smart Signal Indicator
to help nd a location with a strong signal. The more bars lit on
the signal indicator, the stronger the Wi-Fi signal is.
Poor
location
Ideal
location
!
!!
Poor
location
Ideal
location
!
!!

D-Link DAP-1325 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Antenna type	External
Antennas quantity	2
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPA, WPA2, WPS-PBC
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3u
Wi-Fi data rate (max)	300 Mbit/s
Ethernet LAN (RJ-45) ports	1
Certification	FCC, IC, CE, RCM, IDA, CB, LVD, UL, WPS
Product color	Grey, White
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	RoHS
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	50.7 mm
Width	97.9 mm
Height	48.7 mm
Weight	97 g
