D-Link DAP-1325 Quick Install Guide

6 DAP-1325 Install Guide
Connect Your Wireless Devices
5
6
Your device is now connected to the DAP-1325 and can connect to your wireless
router. If you want to change your network settings, password, etc., follow the
steps on the next page to congure the DAP-1325. To connect additional
devices, repeat step 5.
Your setup is complete!
Extended network
Original network
From your wireless device go to the Wireless Utility to display the available
wireless networks.
The SSID on the DAP-1325 will automatically be assigned the following:
• 2.4GHz (Your Router’s SSID)-EXT
The Wi-Fi password for the DAP-1325 will be the same as your router.
Repeat step 5 to connect additional Wi-Fi devices to the DAP-1325.

D-Link DAP-1325 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Antenna type	External
Antennas quantity	2
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPA, WPA2, WPS-PBC
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3u
Wi-Fi data rate (max)	300 Mbit/s
Ethernet LAN (RJ-45) ports	1
Certification	FCC, IC, CE, RCM, IDA, CB, LVD, UL, WPS
Product color	Grey, White
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	RoHS
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	50.7 mm
Width	97.9 mm
Height	48.7 mm
Weight	97 g
