D-Link DAP-1330 Quick Install Guide

DAP-1330 Install Guide 15
Where should I place my DAP-1330 when using it as a range extender?
A Range Extender only works as well as the signal it is extending. Therefore, proper
placement of your DAP-1330 is important in achieving desired results.
A Range Extender only works as well as the signal it is extending.
Therefore, proper placement of your DAP-1330 is important in
achieving desired results.
For best performance, place your DAP-1330 in between your
router and your dead zone, making sure it is placed in a location
where the Wi-Fi signal is still strong. Use the Smart Signal Indicator
to help nd a location with a strong signal. The more bars lit on
the signal indicator, the stronger the Wi-Fi signal is.
Poor
location
Ideal
location
!
!!
Poor
location
Ideal
location
!
!!

D-Link DAP-1330 Specifications

General

Product color	White
LED indicators	Yes
Maximum data transfer rate	100 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3u
Interface	Wi-Fi/Ethernet
Ethernet LAN (RJ-45) ports	1
Security algorithms	WPA, WPA2, WPS
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Operating altitude	5 - 95 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, IC, CE, C-Tick, CB, UL

Weight and Dimensions

Weight	86.9 g
Dimensions (WxDxH)	77 x 55.5 x 34 mm
